FLIR GF 309 Thailand Infrared Camera Specifications


FLIR GF309 is used for high temperature industrial furnace applications. FLIR GF309 is designed to "see through flames" in all types of gas-fired furnaces, chemical heaters, coal-fired boilers. As the camera has an exceptionally wide span of temperature range it will also perform high accuracy electrical and mechanical inspections, making it a very useful instrument for its owner.


Engineered to "See Through Flames"FLIR GF309

The FLIR GF309 is designed for high temperature industrial furnace applications. Thesecameras are ideal for monitoring all types of furnaces, heaters and boilers, particularly in the chemical, petrochemical and utility industries. Custom-built to see through flames, the GF309 also features a detachable heat-shield designed to reflect heat away from the camera and camera operator, providing increased protection.


The FLIR GF309 infrared camera provides temperaturereadings across the entire surface of your heater/boiler/furnace and will help you to inspect faster, work safer and avoid unscheduled shutdowns and, worse, catastrophic failures.


Imaging Performance

Field of view/min focus distance 24° x 18° / 0.3 m
Lens identification Automatic
F-number 1.5
Thermal sensitivity/NETD <25 mK @ +30°C
Focus Automatic (one touch) or manual (electric or on the lens)
Zoom 1–8× continuous, digital zoom
Digital image enhancement Noise reduction filter, scene based NUC, High Sensitivity Mode (HSM)
Focal Plane Array (FPA) / Spectral range Cooled InSb / 3–5 μm
IR resolution 320 × 240 pixels
Detector pitch 30 μm
Sensor cooling Stirling Microcooler (FLIR MC-3)

Electronics and data rate

Full frame rate 60 Hz

Image presentation

Display Built-in widescreen, 4.3 in. LCD, 800 × 480 pixels
Viewfinder Built-in, tiltable OLED, 800 × 480 pixels
Automatic image adjustment Continuous/manual; linear or histogram based
Manual image adjustment Level/span
Image modes IR-image, visual image, High Sensitivity Mode (HSM)

Measurement

Temperature range –40 to +1500°C
Accuracy ±1°C for temperature range (0-100 °C)
or ±2% of reading for temperature range (> +100 °C)

Measurement analysis

Spotmeter 10
Area 5 boxes with max/min/average
Profile 1 live line (horizontal or vertical)
Difference temperature Delta temperature between measurement functions
or reference temperature
Reference temperature Manually set or captured from any measurement function
Emissivity correction Variable from 0.01 to 1.0 or selected from editable materials list
Reflected apparent temperature correction Automatic, based on input of reflected temperature
Measurement corrections Reflected temperature, distance, atmospheric transmission,
humidity, external optics

Set-up

Menu commands Level, span
Auto adjust continuous/manual/semi-automatic
Zoom
Palette
Start/stop recording
Store image
Playback/recall image
Set-up commands 1 programmable button, local adaptation of units, language, date and time formats
Web interface Admin camera setup and viewing IR images

Storage of images

Image storage type Removable SD or SDHC Memory Card, two card slots
Image storage capacity > 1200 images (JPEG) with post process capability per GB on memory card
Image storage mode IR/visual images.
Visual image is automatically associated with corresponding IR image.
File formats Standard JPEG, 14 bit measurement data included
GPS Location data automatically added to every image from built-in GPS

Video recording and streaming

Radiometric IR-video recording 7 Hz direct to memory card
Non radiometric IR-video recording MPEG4/H.264 (up to 60 minutes/clip) to memory card. Visual image can automatically be associated with corresponding recording of non-radiometric IR-video.
Digital camera video recording MPEG4/H.264 (25 minutes/clip) to memory card
Non radiometric IR-video streaming RTP/ H.264

Digital camera

Built-in digital camera 3.2 Mpixel, auto focus, and two video lamps

Laser pointer

Laser Activated by dedicated button

Data communication interfaces

USB USB-A: Connect external USB device (e.g. memory stick)
USB Mini-B: Data transfer to and from PC
USB, standardVideo USB Mini-B: 2.0 High Speed
Video Digital Video Output (image)

Power system

Battery type Rechargeable Li Ion battery
Battery voltage 7.2 V
Battery operating time > 3 hours at 25°C and typical use
Charging system In camera (AC adapater or 12 V from a vehicle) or 2 bay charger
Start-up time < 5 min. @ 25°C


Flir GF309 Thailand


FLIR GF309 is used for high temperature industrial furnace applications. FLIR GF309 is designed to "see through flames" in all types of gas-fired furnaces, chemical heaters, coal-fired boilers. As the camera has an exceptionally wide span of temperature range it will also perform high accuracy electrical and mechanical inspections, making it a very useful instrument for its owner.


Engineered to "See Through Flames"


The FLIR GF309 is designed for high temperature industrial furnace applications. These cameras are ideal for monitoring all types of furnaces, heaters and boilers, particularly in the chemical, petrochemical and utility industries. Custom-built to see through flames, the GF309 also features a detachable heat-shield designed to reflect heat away from the camera and camera operator, providing increased protection.


The FLIR GF309 infrared camera provides temperature readings across the entire surface of your heater/boiler/furnace and will help you to inspect faster, work safer and avoid unscheduled shutdowns and, worse, catastrophic failures.
